  Solutions
PCB Solutions


One-stop PCB Solutions

 PCB Design

Our qualified and experienced design team uses the established and proven high-end CAD/CAM tools to design the PCB, not just PCB designers, they can also offer you valuable experiences in electronics, high-speed digital and analog design.
Our PCB designers and team are fully conversant with current and manufacturing technology, we also consider the Design for Manufacturability (DFM) and Design for the Environment (DFE) according to the IPC-2220, IPC-D-279 etc standards

Our Singapore design team provide PCB layout and PCB routing services:

                -Single to Multi-layer PCB Design
                -High Speed and RF PCB Design
                -High Desity (HDI) and Build up Board Design
                -Mixed-signal Design and Rigid Flex Design
                -Impedance Control and EMI/EMC Compliance
                -Blind Buried Via and Via in Pad
                -Burn-in Board and Probe Card Design


 PCB Fabrication

Our PCB factory located in Shenzhen, China, It established in 2001, which specializes in the production of single, double sided, Multilayers and special PCB boards. The company has 700 staff, plant area of 20000sqm and monthly output of 50000sqm. The product involves many area, such as home electronic, audio/video product, cars industry, figures consumes industry, aerospace manufacturing industry etc

We offer a wide range of PCBs such as single-sided, double-sided, multi-layer, high frequency, HDI board, MCPCB, metal-backed PCB and so on
Surface finish (HASL LF, Immersion gold, Immersion Tin, Immersion silver, OSP etc)
The quality of our products come up to IPC standard which assure that we provide you with high quality, cost-effective PCB on-time. The PCB fabication will follow Standards IPC-A-600, IPC-D-275, IPC-RB-276 etc



 PCB Assembly

Our Singapore factory provide PCB Assembly, SMT Services, and have three fully automatic assembly production line which can fulfill your requiments, the PCB assembly will follow the standard IPC-A-610F, IPC-7711A, class 2 and class 3 etc

PCB Assembly Capability:

    -SMT from 0201 and Through Hole
    -One-sided as well as double-sided, multi-layers PCB assembly
    -Simple to very complex and Flex PCB assemblies
    -Capability to handle any devices including BGAs, QFNs, DFNs, CSPs, Flip Chip etc
    -Small quantities and quick turns available
    -Consigned Components or Turnkey
    -RoHS & Lead-Free Assembly
    -BGA rework and Flip Chip rework services, X-Ray equipment available

    -Automated Optical Inspection (AOI)
    -In-circuit and Functional Test (ICT & FCT)
